8 Ton Single Drum Vibratory Compactor Roller
Type number: HSR8000
Weight: 8 ton
8 ton single drum vibratory compactor roller
Products Introduction
The HSR8000 single drum roller compactor offers optimum compaction results with excellent maneuverability, grade ability and stability. The compact design provides for an excellent view of the work area and drum from the operator’s seat. The spacious operator platform is isolated from vibration for comfortable operation. It is ideal for commercial and residential projects, secondary roads and parking lots.

Main Parameters
Model | HSR8000 |
Operating Weight | 8000 kg |
Exciting Force | 110 KN |
Vibration Frequency | 40 HZ |
Drum Width | 1700 / 1230 mm |
Static Liner Load | 242 N/cm |
Travel Speed | 0-15 Km/h |
Grade Ability | 30% |
Min Turning Radius | 7500 mm |
Wheelbase | 2560 mm |
Min Ground Clearance | 350 mm |
Diesel/Hydraulic tank Capacity | 100 / 100 L |
Bettery Voltage | 24 V |
Diesel Model | CZ4102T |
Rated power | 48 KW |
Overall Dimension(L×W×H) | 4900×1870×2580 mm |
1,Three-point articulated pendulum joint provides for even weight distribution and consistent compaction, even when navigating curves and uneven ground conditions.
2,The driver’s cabin with ROPS is standard equipment.
3,Rear wheels are driven by independent motors resulting in excellent ground clearance.
4,Quick and easy maintenance with all access points located on one side of the machine
5,Excellent traction in a variety of conditions, enhancing productivity and safety.
Application
HSR8000 single drum compactor roller are robust, versatile and compactly designed and it is suitable for all compaction work in earthworks and road construction.

Our Service
1. OEM order accepted: Customer’s brand, Color etc.
2. Spare parts in stock.
3. Factory visiting, third party inspection etc.
4. We will reply for your inquiry in 24 hours.
5. Purchasing agent for related machines.
